B05PNP NPN (NO/NC)
BKT0001 - Contrast Sensor
BKT0001 - Contrast Sensor
Regular price
$706.17 NZD
Regular price
Sale price
$706.17 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Contrast Sensor
Alu Block RGB PNP/NPN (NO/NC) M12.
Compatible Part Numbers:
BKT0001
Typecode / BKT 67M-001-U-S92
Technical Data Of: BKT0001
| Series | 67M |
| Dimension | 32 x 64 x 82 mm |
| Interface |
PNP/NPN NO/NC Analog, voltage 1…5.5 V
|
| Input function | Time function on/off |
| Principle of operation | Contrast sensor |
| Principle of optical operation | Diffuse sensor, focused |
| Beam characteristic | Focused |
| Light type | blue light/green light/red light |
| Light spot size | 1.5 x 5 mm at 9 mm |
| Range | 6...12 mm |
| Connection | Connector, M12x1-Male |
| Housing material | Aluminium, Die casting, Painted |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | CE |
| UKCA | |
| cULus | |
| WEEE |
Technical Data Sheet:
1 in stock
