BCC0F36- Single-Ended Cordsets - Sheilded M12x1-Female, straight, 8-pin, 50metre
BCC0F36- Single-Ended Cordsets - Sheilded M12x1-Female, straight, 8-pin, 50metre
Regular price
$582.75 NZD
Regular price
Sale price
$582.75 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Single-Ended Cordsets
M12 Straight 8pin PUR Shielded 50m Female
Special Order item. Usually 20 days lead time
Details:
When you purchase this item, you'll receive a high-quality cable from one of our listed brands, found under Compatible Part Numbers. Brands include Balluff, Reer, and PepperL Fuch. If you have a specific preference, please let us know, and we'll do our best to accommodate your request.
| Key Features | Details |
| Connection | M12x1-Female, straight, 8-pin, A-coded |
| Cable | PUR Shielded black, 50 m, Drag chain compatible |
| Number of conductors | 8 |
| Conductor cross-section | 0.25 mm² |
| Cable temperature, fixed routing | -50...90 °C |
| Cable temperature, flexible routing | -25...90 °C |
| Operating voltage Ub | 30 VDC / 30 VAC |
| Rated current (40 °C) | 2.0 A |
| IP rating | IP67 |
| Approval/Conformity | CE, cULus, UKCA, WEEE |
| Additional product information | "Customs tariff numbers: |
| Weight (in kg): 2.838 | |
| Country of origin: | |
| Product groups key: PA009PG045" |
Compatible Part Numbers:
BCC M418-0000-1A-046-PS0825-5
BCC0F36
Technical Data Sheet:
