B20PNP (NO)
BCS00M8 - Capacitive Sensors For Object Detection
BCS00M8 - Capacitive Sensors For Object Detection
Regular price
$151.44 NZD
Regular price
Sale price
$151.44 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Capacitive Sensors For Object Detection
M18 PNP (NO) Connector, M12x1-Male, 3-pin.
Compatible Part Numbers:
BCS00M8
Typecode / BCS M18BBI3-PSC80D-S04K
Technical Data Of: BCS00M8
| Dimension | Ø 18 x 88.5 mm |
| Series | M18 |
| Thread (A) | M18x1 |
| Installation |
for flush mounting
|
| Connection |
Connector, M12x1-Male, 3-pin
|
| Switching output |
PNP normally open (NO)
|
| Switching frequency | 100 Hz |
| Range | 1...8 mm |
| Sensitivity |
Switching distance adjustable
|
| Housing material | PBT |
| Material sensing surface | PBT |
| Ambient temperature | -25...85 °C |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | CE |
| UKCA | |
| cULus | |
| WEEE | |
| IP rating | IP67 |
Technical Data Sheet:
1 in stock
