K0771 Kipp Position indicators freely programmable

K0771 Kipp Position Indicators - Freely Programmable

Special Order Item

3- 4 week lead time

Overview

Introducing the K0771 Kipp Electronic Position Indicators, now available at Southern Technology Ltd. These advanced indicators surpass traditional mechanical position indicators, offering the ability to display angles, handle uncommon spindle pitches, and record every fraction of spindle movement with precision.

Key Features

• Freely Programmable Parameters: Customize your settings easily using the K0411.09 programming software.
• Durable Construction:
  • Housing: Made of robust plastic
  • Hollow Shaft: High-quality steel, black oxidized
  • Screen: Clear and easy-to-read LCD display
  • Grub Screw: Reliable steel, black
• Technical Specifications:
  • Display: LCD with 5 digits (approx. 8 mm in size), display range from -19999 to 99999
  • Hollow Shaft Diameter: 14 H7 mm
  • Operating Temperature: -10 °C to +60 °C
  • Storage Temperature: -30 °C to +80 °C
  • Maximum Revolution: 600 rpm
  • Battery: Long-lasting lithium button cell 3V, type CR 2032, with a service life of approximately 2 years
  • Vibration-Resistance: DIN IEC 68-2-6 standards, 10 g / (5 … 150 Hz), 20 g / (100 … 2000 Hz)
  • Shock-Resistance: DIN IEC 68-2-27 standards, 30 g / 15 ms
  • EMC Compliance: DIN EN 61000-4-2; DIN EN 61000-4-4
  • Protection Class: IP 51
• Functionalities:
  • Programmable indicated value and decimal point
  • Switchable between linear or angle mode
  • Function key for zero-point positioning
  • Easily switch between absolute dimension and chain dimension
  • Direct programming of an offset value at the device
  • Simple battery replacement for continuous operation

Accessories

• Reducing Bushes: K0412
• Programming Software: K0411.09

Why Choose K0771 Kipp Position Indicators?

The K0771 Kipp Position Indicators are ideal for applications requiring precise measurement and easy programmability. With their robust performance and durability, these indicators are perfect for a wide range of environments and applications.

Order Now

Upgrade your measurement capabilities with the K0771 Kipp Position Indicators. Order now from Southern Technology Ltd and experience the difference in precision and programmability.
