OBD18-200-PNP-M12 CRUX- 087991 - Diffuse Mode Sensor
OBD18-200-PNP-M12 CRUX- 087991 - Diffuse Mode Sensor
Regular price
$257.55 NZD
Regular price
Sale price
$257.55 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Diffuse mode sensor, OBD18-200-PNP-M12 CRUX- Diffuse Mode Sensor
- Dual color indication LED
- High switching frequency
- Light-on/dark-on, programmable
- Strong metallic housing in cylindrical shape M18 x 1
- Degree of protection IP45
Details: OBD18-200-PNP-M12 CRUX- Diffuse Mode Sensor
Compatible Part Numbers:
OBT200-18GM60-E5-V1 - discontinued. Equivalent* light / dark mode selection and pnp output
*no short circuit protection.
087993
Datasheet excerpt: Technical data of OBD18-200-PNP-M12 Crux
| General specifications | ||
|---|---|---|
| Detection range | 0 ... 200 mm | |
| Reference target | standard white 200 mm x 200 mm | |
| Light source | IRED , 880 nm | |
| Light type | infrared | |
| Diameter of the light spot | approx. 40 mm at 200 mm | |
| Ambient light limit | 10000 Lux | |
| Indicators/operating means | ||
| Operation indicator | LED green | |
| Function indicator | Dual color-LED, yellow/green yellow: switch state green: power on flashing: stability control |
|
| Control elements | Sensing range adjuster | |
| Electrical specifications | ||
| Operating voltage | 10 ... 30 V DC , class 2 | |
| Ripple | 10 % | |
| No-load supply current | ≤ 25 mA | |
| Time delay before availability | ≤ 25 ms | |
| Output | ||
| Switching type | light/dark on electrically switchable | |
| Signal output | 1 PNP output, | |
| Switching voltage | max. 30 V DC | |
| Switching current | max. 100 mA | |
| Voltage drop | ≤ 2.5 V | |
| Switching frequency | 500 Hz | |
| Response time | 1 ms | |
| Ambient conditions | ||
| Ambient temperature | -25 ... 55 °C (-13 ... 131 °F) | |
| Storage temperature | -40 ... 70 °C (-40 ... 158 °F) | |
| Mechanical specifications | ||
| Degree of protection | IP67 | |
| Connection | 4-pin, M12 x 1 connector | |
| Material | ||
| Housing | brass, nickel-plated | |
| Optical face | PC | |
| Mass | 45 g | |
| Dimensions | ||
| Length | 60 mm | |
| Diameter | 18 mm | |
