PF 088834 - Diffuse Mode Sensor

PF 088834 - Diffuse Mode Sensor

Regular price $633.11 NZD
Regular price Sale price $633.11 NZD
Sale Sold out
Shipping calculated at checkout.

Price (exc. GST) each

Diffuse Mode Sensor, 088834

  • Infrared light
  • Light-on/dark-on, switchable
  • Timer function
  • Degree of protection IP67

Details : 088834

Compatible Part Numbers :

088834

RLK39-8-800-Z/31/40a/116

Technical Data Sheet :

Datasheet excerpt: Technical data of  RLK39-8-800-Z/31/40a/116

General specifications
Detection range 0 ... 800 mm
Adjustment range 150 ... 800 mm
Reference target standard white 200 mm x 200 mm
Light source IRED
Light type modulated infrared light
Ambient light limit IEC / EN 60947-5-2 , 10000 Lux
Functional safety related parameters
MTTFd 803 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
Indicators/operating means
Function indicator LED yellow: switching state
LED red: pre-fault indication
Control elements Sensing range adjuster, light-on/dark-on changeover switch
Control elements switch for timer function
Electrical specifications
Operating voltage 12 ... 240 V DC
24 ... 240 V AC (50 ... 60 Hz)
Ripple 10 %
No-load supply current ≤ 50 mA
Protection class II, rated voltage ≤ 250 V AC with pollution degree 1-2 according to IEC 60664-1 Caution!
The protection class 2 is only valid when the terminal compartment is closed. output circuit has basic insulation to control circuit according to IEC/EN 61140
Power consumption ≤ 3 VA
Time delay before availability ≤ 300 ms
Output
Switching type light/dark on
Signal output 1 relay output
Switching voltage max. 240 V AC ; 150 V DC
Switching current max. 3 A
Switching power DC: max. 90 W AC: max. 750 VA
Switching frequency ≤ 25 Hz
Response time ≤ 20 ms
Timer function On-/off-delay or pulse extension on choice
Conformity
Product standard EN 60947-5-2
Approvals and certificates
CCC approval Certified by China Compulsory Certification (CCC)
Approvals CE
Ambient conditions
Ambient temperature -25 ... 55 °C (-13 ... 131 °F)
Storage temperature -40 ... 70 °C (-40 ... 158 °F)
Mechanical specifications
Degree of protection IP67
Connection terminal compartment PG9, ≤ 2.5 mm2
Material
Housing PBT
Optical face PMMA
Mass approx. 110 g
Dimensions
Height 64 mm
Width 25 mm
Depth 75 mm
General information
Scope of delivery Mounting aid



Classifications

System Classcode
ECLASS 13.0 27270903
ECLASS 12.0 27270903
ECLASS 11.0 27270903
ECLASS 10.0.1 27270903
ECLASS 9.0 27270903
ECLASS 8.0 27270903
ECLASS 5.1 27270903
ETIM 9.0 EC001821
ETIM 8.0 EC001821
ETIM 7.0 EC001821
ETIM 6.0 EC001821
ETIM 5.0 EC001821
UNSPSC 12.1 39121528

1 in stock
