B8PNP (NO)
Balluff - M12 PNP (NO) - Diffuse Sensor BOS01Y3
Balluff - M12 PNP (NO) - Diffuse Sensor BOS01Y3
Regular price
$138.36 NZD
Regular price
Sale price
$138.36 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Diffuse Sensor
M12 PNP (NO) Cable PVC Sn: 1-200mm
Compatible Part Numbers:
BOS01Y3
Typecode / BOS 12M-PS-RD12-02
Technical Data Of: BOS01Y3
| Series | 12M |
| Dimension | Ø 12 x 60 mm |
| Interface |
PNP normally open (NO)
|
| Principle of operation |
Photoelectric sensor
|
| Principle of optical operation |
Diffuse sensor, energetic
|
| Beam characteristic | Divergent |
| Light type | LED, red light |
| Light spot size |
22 x 22 mm at 200 mm
|
| Range | 1...200 mm |
| Connection |
Cable, 2.00 m, PVC
|
| Housing material |
Brass, nickel-plated
|
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | CE |
| UKCA | |
| cULus | |
| WEEE | |
| Trademark | Global |
Technical Data Sheet:
1 in stock
