Balluff - 24VDC - Power Supply BAE0111
Balluff - 24VDC - Power Supply BAE0111
Regular price
$178.22 NZD
Regular price
Sale price
$178.22 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Power Supplies For The Control Cabnet
DIN rail Terminal, 0.25...2.5 mm²
Compatible Part Numbers:
BAE0111
Typecode / BAE PS-XA-1W-24-025-016
Technical Data Of: BAE0111
| Dimension | 27 x 123.6 x 102 mm |
| Version | DIN rail |
| Mounting part | DIN rail mount |
| Housing material | Plastic |
| Connection | Terminal, 0.25...2.5 mm² |
| Input voltage | 100…240 V AC, 1-phase |
| Rated output voltage DC | 24 V |
| Rated output current | 3.12 A |
| IP rating | IP20 |
| Approval/Conformity | CE |
| cURus | |
| cULus | |
| WEEE | |
| Ambient temperature | -20...70 °C |
Technical Data Sheet:
1 in stock
