B13NPN (NO/NC)
Balluff - NPN (NO/NC) - Retroreflective Sensor BOS01JR
Balluff - NPN (NO/NC) - Retroreflective Sensor BOS01JR
Regular price
$264.45 NZD
Regular price
Sale price
$264.45 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Retroreflective Sensor
NPN (NO/NC) Cable PVC Sn: 10m
Compatible Part Numbers:
BOS01JR
Typecode / BOS 5K-NU-LR10-02
Technical Data Of: BOS01JR
| Series | 5K |
| Dimension | 10.8 x 32.7 x 19.5 mm |
| Interface |
NPN normally open/normally closed (NO/NC)
|
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Retroreflective sensor |
| Beam characteristic | Divergent |
| Light type | Laser red light |
| Light spot size | Ø 5 mm at 3 m |
| Range | 0...10 m |
| Connection | Cable, 2.00 m, PVC |
| Housing material | lPC |
| PBT | |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | cULus |
| CE | CE |
| WEEE | WEEE |
| UKCA | UKCA |
Technical Data Sheet:
2 in stock
