B7NPN (NO)
Balluff - NPN (NO) - Diffuse Sensor BOS0116
Balluff - NPN (NO) - Diffuse Sensor BOS0116
Regular price
$187.76 NZD
Regular price
Sale price
$187.76 NZD
Unit price
per
Shipping calculated at checkout.
Price (exc. GST) each
Couldn't load pickup availability
Diffuse Sensor
NPN (NO) Cable PVC Sn: 900mm
Compatible Part Numbers:
BOS0116
Typecode / BOS 5K-NS-ID10-02
Technical Data Of: BOS0116
| Series | 5K |
| Dimension |
10.8 x 32.7 x 19.5 mm
|
| Interface |
NPN normally open (NO)
|
| Principle of operation |
Photoelectric sensor
|
| Principle of optical operation |
Diffuse sensor, energetic
|
| Beam characteristic | Divergent |
| Light type | Infrared |
| Range | 0...900 mm |
| Connection |
Cable, 2.00 m, PVC
|
| Housing material | PC |
| PBT | |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | cULus |
| CE | |
| WEEE | |
| UKCA | |
| Trademark | Global |
Technical Data Sheet:
2 in stock
